Specifications
| Table size (mm) | 450 × 450, 500 × 500, 800 * 800, 1000 * 1000mm or other |
| Amplitude | 10mm |
| Maximum test Weight | 100kg |
| Acceleration | 0~20g |
| vibration waveform | Sine wave (half wave, full wave) |
| Sweep function (1~ 5000Hz) | (Upper Frequency/Lower Frequency/Timer Range) You can arbitrarily set the true standard back and forth frequency sweep. |
| Programmable function (1~ 5000Hz) | 1 to 15 segments, the time and Frequency of each segment can be set arbitrarily to achieve the cycle detection function |
| Frequency doubling function (0.01Hz) | 15-segment multiple increase, ① low to high frequency ② high to low frequency ③ bottom to high frequency and then to high frequency, recyclable |
| Logarithmic function (0.01HZ) | ① Low to high frequency ② High to low frequency ③ Low to high and then to low frequency/three modes, recyclable |
| vibration direction | ① Vertical (Y axis), ② Horizontal (X, Z axis), ③ Vertical + Horizontal (Y, X, Z axis) |
| Precision | Frequency can be displayed to 0.01HZ, precision 0.1HZ |
| time control | Any time can be set (in seconds) |
