Specifications
| Capacity | 0~1T (can be customized according to customer requirements) |
| Accuracy grade | Level 1 |
| Control mode | Two-position (both the computer host and the microcomputer LCD monitor can be tested separately) |
| Display mode | Electronic LCD display and computer display |
| Force Unit | kgf，gf ，N，kN，lbf |
| Unit switch | MPa，kPa，kgf/cm2，lbf/in2 |
| displacement unit | mm、cm、in |
| Analysis | 1/100000 |
| Display resolution | 0.001N |
| Working Travel | 1000mm |
| Plate size | 800*800 |
| Pressurization speed | 5~100mm/min |
| software function | Chinese and English language swap |
| shutdown mode | overload shutdown, emergency stop button, automatic shutdown for test piece damage, automatic shutdown for Upper/Lower limit setting |
| Safety Devices | Overload protection, limit element protection device |
| Machine power | AC variable frequency motor drive Controller |
| Mechanical system | High-precision ball screw |
| Power | AC220V/50HZ~60HZ 4A |
| Machine Weight | About 850KG |
