Specifications
| Screening area | 54200m㎡ |
| 304 stainless steel screen frame size | 311mm×292mm |
| Factory sieve plate sieve seam specifications | 0.25mm (seam width can be customized) |
| Slurry vibration frequency | 400--3000 times/min, manual adjustment, digital display |
| Rubber film drive amplitude | 3.2±0.1mm |
| Size of slurry cylinder (length × width × height) | 320mm×270mm×300mm |
| Motor power | 750W |
| Gear reducer speed | 200~1000r/min |
| Dimensions | 1100*360*880mm |
| Standards | TAPPI275. |
| Water source requirements | The water flow rate is 8.6 L/min; the water pressure is 1.23 Kg/cm2 |
Packing list
Host X1, operation manual X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/34098/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
