Specifications
| Maximum test force | 2000N |
| Friction torque Measurement Range | 0~20N.m |
| Rotation speed of Upper/Lower specimen shafts | 0—600r/min |
| The maximum axial moving distance of the sample | ±4mm |
| Test force indication relative error | Above 10% of full scale, no more than +/- 2% |
| Test force indication Repeatability relative error | Above 10% of full scale, no more than 2% |
| Friction moment indication relative error | Above 10% of full scale, no more than +/- 2% |
| Friction torque indication Repeatability relative error | Above 10% of full scale, no more than 2% |
| Temperature control range | Room temperature -60 ℃ |
| Time control range | 1s-9999min |
| RPM control range | 1-99999999 |
| Time-friction moment Linear dispersion | The measurement display and data processing of each parameter are realized by the computer, and the time-friction moment Linear dispersion can be displayed in real time. |
| Dimensions | 970*660*1100mm |
| Weight | Approx. 500kg |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/34101/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
