Specifications
| Measurement range of standard pendulum | (10~1000) mN, Graduation 10mN |
| pendulum | (10~1000) mN, Graduation 5mN (optional) |
| lightest pendulum | (10~200) mN, Graduation 2mN (optional) |
| Error of indication | 20% - 80% of the upper limit of measurement +/- 1% within the range, +/- 0.5% FS outside the range |
| Repeatability Error | 20% - 80% of the upper limit of measurement < 1% within the range, < 0.5% FS outside the range |
| Tear arm | 104±1mm |
| tearing initial angle | 27.5±0.5° |
| tear distance | 43±0.5mm |
| Paper surface size | 25×15mm |
| Distance between clamps | 2.8±0.3mm |
| Specimen size | (63±0.5)mm*(50±2)mm |
| Operating Conditions | Celsius temperature: 23, Relative Humidity 50% +/-5 |
| Dimensions | 420*300*465mm |
| Mass | 25㎏. |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
