Specifications
| Measurement range of standard pendulum | (10~13000) mN Graduation 10mN |
| Error of indication | +/- 1% within the range of 20% to 80% of the upper limit of measurement, +/- 0.5% FS outside the range |
| Repeatability Error | < 1% in the range of 20% to 80% of the upper limit of measurement, < 0.5% FS outside the range |
| Tear arm | 104±1mm |
| tearing initial angle | 27.5±0.5° |
| tear distance | 43±0.5mm |
| Paper surface size | 25×15mm |
| Distance between clamps | 2.8±0.3mm |
| Specimen size | (63±0.5)mm*(50±2)mm |
| Operating Conditions | Temperature 20 +/- 10 ℃ Relative Humidity ≤ 80% |
| Dimensions | 460*400*400mm |
| Power Supply | AC220V±5% 50Hz |
| Mass | 30kg |
Packing list
host X1, power cord X1, manual X1, certificate X1, warranty card X1, printing paper X4
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/34171/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
