Specifications
| Analog D65 lighting body lighting | Adopt CIE 1964 to supplement chroma system and CIE 1976 (L * a * b) color space Color difference formula |
| Geometry conditions observed with D/O illumination | Diffuse ball diameter 150MM, test hole diameter 25MM |
| Repeatability | δ(Y10)＜0.1,δ(X10.Y10)＜0.001 |
| Precision | △Y10＜1.0,△X10(Y10) ＜0.01. |
| Specimen size | The test plane is not less than Should 30MM, thickness is not more than 40MM |
| Power Supply | AC220V±5%,50Hz,0.3A |
| Operating Environment | Temperature 10~30 ℃, Relative Humidity does not exceed 85% |
| Dimensions | 300×380×400mm |
| Weight | 15KG |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/34304/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
