Specifications
| Explosion-proof Certificate number | CNEx16.0449 |
| Explosion-proof sign | Exd ⅡC T6 Gb |
| response time | <30S |
| Working Voltage | DC24V±10% |
| Ambient Operating Temperature | -20℃～50℃ |
| Output current | 4-20mA |
| Ambient Operating Humidity | 0-95% RH (non-condensing) |
| Relay control port | Passive relay output, full load power 1kW |
| signal output | 3-Wire 4~ 20mA or 4-wire RS485 |
| Installation method | wall mount |
| shell material | die casting aluminum |
| Dimensions | 190 * 150 * 95Mm (length * width * thickness) |
Packing list
Whole machine X1, Encasement box X1, Charger X1, Calibration cover X1, Manual X1, Certificate X1, Warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/34338/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
