Specifications
| Probe Type | F1 and N1 |
| Measurement principle | Magnetic induction + eddy current |
| Measuring range | 0 ~ 1250µm |
| Low limit resolution | 1mm |
| A little indication of calibrating error | ±（3%H+1） |
| Two-point indication of calibrating error | ±[（1~3%)H+1] |
| Minimum radius of curvature | Convex 5mm, concave 10mm |
| Minimum measurement surface | F10mm |
| Minimum substrate Film thickness | 0.3mm |
| temperature | 0~40℃ |
| Humidity | 20%~90% |
| Power | AAA type alkalinity battery 1.5V four |
| Dimensions | 150 * 55.5 * 23mm (host) |
| Weight | 120g |
| Standard configuration | Main unit, standard test piece, substrate, AAA alkalinity battery |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/34688/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
