Specifications
| Power | （100~240）VAC 2A 50/60Hz |
| Error of indication | ±1% |
| Indication variability | ≤1% |
| Resolution | 0.1mN |
| Measurement range | 20~10000mN (equivalent bending moment is 1~ 500mN.m) |
| bending length | 50mm；25mm；10mm；(±0.5mm) |
| bending angle | Adjustable from 1 to 90 degrees |
| Display | 5 "Color touchscreen |
| printout | Thermal printer, printing high-speed mute |
| Communication interface | RS232 (standard)/USB (optional) |
| Environmental conditions | Indoor temperature (20 +/- 10) ℃, Relative Humidity < 85% |
| Dimensions | 320*300*300mm |
| Net Weight | 16 kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/34747/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
