Specifications
| Power | AC220V±10% 2A 50Hz |
| Error of indication | ±1% |
| Indication variability | <1% |
| Force resolution | 0.01N |
| Force range | 10~500N |
| Specimen holder free spacing | 0.7±0.05mm |
| Specimen width | 15mm |
| Sample holding force | 2300±500N |
| Pressurization speed | 3±1mm/min |
| Communication interface | RS232 (std.)/USB (optional) |
| Dimensions | 466*410*360mm |
| Weight | About 42kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/34764/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
