Specifications
| Power | (100~240)VAC 2A 50/60Hz |
| Error of indication | A file: < 6J Graduation ： +/- 0.05J; B file: < 12J Graduation ： +/- 0.1J; C file: < 24J Graduation ： +/- 0.2J; D file: < 48J Graduation ： +/- 0.5J; |
| Resolution | ±0.5J |
| Measurement range | <48J |
| clamping pressure | 250N~1000N |
| Friction sleeve resistance | <0.25J |
| show | 5 "Color touchscreen |
| printout | modular integrated thermal printer |
| Communication interface | RS232 (std.)/USB (optional) |
| Operating Environment | Indoor temperature (20 +/- 10) ℃ Relative Humidity < 85% |
| Dimensions | 865*495*780mm |
| Net Weight | About 165kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/34770/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
