Specifications
| Power | (100~240)VAC 2A 50/60Hz |
| Error of indication | ±1% |
| Indication variability | ＜1% |
| Resolution | 0.1N |
| Force range | 35~7000 N |
| deformation error | ≤ ±0.1 mm |
| Plate size | 260*260 mm |
| Plate parallelism | ≤0.5mm |
| Working Travel | 10~350mm |
| Pressurization speed | 12.5 mm/min (1~ 150mm/min can be set) |
| return speed | 5~150mm/min |
| monitor | 7 "Color touchscreen |
| printout | modular integrated thermal printer |
| Communication interface | RS232 (std.)/USB (optional) |
| Operating Environment | Indoor temperature (20 +/- 10) ℃; Relative Humidity < 85% |
| Dimensions | 535*425*805mm |
| Weight | About 81kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/34782/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
