Specifications
| Power | (100~240)VAC 2A 50/60Hz |
| Force range | 0.001~10N |
| Resolution | 0.001N |
| Error of indication | ±1% |
| Specimen thickness | ≤0.2mm |
| Slider size | 63*63mm |
| Slider Mass | 200g±2g |
| Work surface size | 120*240mm |
| Slider traverse speed | 100±10mm/min |
| Display mode | 7 "color touchscreen |
| printout | modular integrated thermal printer |
| communication output | WIFI, RS232 (std.)/USB (optional) |
| Operating Environment | Indoor temperature 10 ℃~ 30 ℃; Relative Humidity ≤ 80% |
| Dimensions | 410*314*300mm |
| Net Weight | Approx. 20 kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/34787/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
