Specifications
| Measurement parameters | Ra、Rz、Rq、Rt |
| Measurement range | Ra:0.05-10.0μm；Rz:0.1-50μm |
| Sampling length | 0.25mm、0.8mm、2.5mm； |
| evaluation length | 1.25mm、4mm、5mm |
| scan length | 6mm |
| Error of indication | ≤±10％ |
| Indication variability | <6％ |
| Sensor type | piezoelectric crystal |
| Stroke length | 6mm |
| Probe stylus tip arc radius and angle | Radius of needle tip arc: 10.0 +/- 2.5μm; Angle: 90 ° |
| Sensors Static force measurement of contact pins | Static force of contact pins: ≤ 0.016N; |
| Sensors Stylus Change Rate | Force change rate: ≤ 800N/m. |
| Sensors Guide Pressure | ≤0.5N |
| Power | 3.7V lithium polymer battery |
| Operating temperature | 0℃- 40℃ |
| Weight | 200g |
| exterior size | 105×70×24mm |
| Charger | DC 5V,500mAh， |
| Standard configuration | Host, power adapter, standard block, file, etc |
