Specifications
| Rated Voltage | AC 220V 50/60 Hz |
| Power | 145W |
| Speed range | 5000~35000rpm |
| Speed regulation mode | Speed control turntable, stepless speed regulation 6 gears |
| Rotor maximum linear velocity | 18m/s |
| Work head material | Stainless steel 304 # |
| Adapt work head | 6G 8G (optional) |
| Ambient Temperature | Not more than 40 ℃ |
| Allowable Relative Humidity | Not more than 80% |
| Dimensions | 380*80*50 mm |
| Machine Weight | 1kg |
| Work head specification | 10G |
| Processing Capacity | 30~250mL |
| Max. Processing Viscosity | 200mpa.s |
| Rotor maximum linear velocity | 13m/s |
| Minimum immersion liquid height | 20mm |
| Working head length | 10mm |
| Operating temperature(MAX) | 120℃ |
| Work head material | SS304 |
| Bearing material | PTFE |
| Maximum immersion liquid height | 110mm |
Packing list
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/34803/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
