Specifications
| Rated Voltage | AC 220V 50/60 Hz |
| output power | 500W German motor |
| Speed range | 7000~28000rpm |
| Speed regulation | Scale stepless speed regulation (optional digital display running monitor) |
| Work head material | Stainless steel 316 # |
| Standard working head | 25G work head selection, please see the work head selection table |
| Allowable environment temperature | Not more than 40 ℃ |
| Allowable Relative Humidity | Not more than 80% |
| Dimensions | 215*310*720 mm |
| Total Weight | 9.7 kg (Gross Weight: 11.0 kg) |
| Standard throughput | 50~3000mL |
| Maximum Max. Viscosity | 4000cp |
| Rotor maximum linear speed | 20m/s |
| Maximum immersion liquid height | 190mm |
| stator diameter | 20mm |
| Operating temperature(MAX) | 120℃ |
| Work head material | 316 |
| Bearing material | PTFE |
Packing list
Host X1, working head X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/34808/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
