Specifications
| Power | 220V/50Hz |
| Motor power | 500W |
| Speed range | 10000~28000rpm |
| Flow rate | 1-15L/min |
| Max. Processing Viscosity | Within 5000 cp |
| Speed regulation mode | Electronic stepless speed regulation |
| Rotation speed display | None (scale display) |
| Standard working chamber | Stainless steel jackless working chamber |
| Standard working head | 25G |
| Contact material | SUS316L |
| Mechanical sealing material | SiC, FKM, ceramics |
| Import and export outer diameter | 14Mm (hose interface) |
| Dimensions | 477*120*122 |
| Work bracket, base, disassembly and assembly tools | Stainless steel standard |
| Ambient Temperature | 5-40° |
| Allowable Relative Humidity | 80% |
| Dimensions | 450*100*120mm |
| Encasement Weight approx | 6KG Carton Foam Encasement |
Packing list
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/34812/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
