Specifications
| Rated Voltage | AC 220V 50/60 Hz |
| output power | 500W |
| Speed range | 1000~28000rpm |
| Rotation speed display | TFT-LCD |
| Timer | 1-1000 min |
| Rotation speed dynamic detection function | Yes |
| Overload protection | Yes |
| Real-time torque Linear dispersion display | Yes |
| Real-time Voltage, Current, Frequency, Power Display | Yes |
| Work head material | Stainless steel 316L # |
| Work head specification | 12/18/25/30/36G (standard 25G) |
| Ambient Temperature | Not more than 40 ℃ |
| Allowable Relative Humidity | Not more than 80% |
| Dimensions | 215*310*720 mm |
| Machine Weight | Approx. 9.2kg (Gross Weight: 11.0kg) |
| Work head specification | 18G |
| Processing Capacity | 50~1500mL |
| Max. Processing Viscosity | 2000cp |
| Rotor maximum linear velocity | 15m/s |
| Maximum immersion liquid height | 160mm |
| stator diameter | 18mm |
| Operating temperature(MAX) | 120℃ |
| Work head material | SS316 |
| Bearing material | PTFE |
| Minimum immersion liquid height | 45mm |
Packing list
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/34818/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
