Specifications
| Rated Voltage | AC 220V 50/60 Hz |
| output power | 800W |
| Speed range | 1000~12000rpm |
| Rotation speed display | TFT-LCD |
| Timer | 1-1000 min |
| Rotation speed dynamic detection function | Yes |
| Overload protection | Yes |
| Real-time torque Linear dispersion display | Yes |
| Real-time Voltage, Current, Frequency, Power Display | Yes |
| Rotor maximum linear velocity | 22m/s |
| Work head material | Stainless steel 304/316L # |
| Work head specification | Φ90 mm |
| Maximum immersion liquid height | 50mm |
| Stator standard configuration | round hole, one long hole working head each. |
| Processing Capacity | 800~30000mL |
| Max. Processing Viscosity | 8000 cp |
| Ambient Temperature | Not more than 40 ℃ |
| Allowable Relative Humidity | Not more than 80% |
| Dimensions | 215*310*720 mm |
| Machine Weight | About 11kg |
| Minimum immersion liquid height | 50mm |
Packing list
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/34824/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
