Specifications
| Temperature range | -40~150℃ |
| Temperature fluctuation | ±0.5℃ |
| Temperature Uniformity | ≤±2℃ |
| Humidity control range | 20~98%R.H |
| Input power | 3.5Kw |
| Power | Single phase 220V 50HZ |
| Interior size | 400*500*500mm |
| Dimensions | 1080*1450*1100mm |
| Interior Volume | 100L |
| Noise | ≤65dB |
| wind speed | 1.7~2.5m/s |
| Humidity Deviation | ≤3% |
| Heating rate | RT + → 150 ℃ │ 40min (no-load nonlinear) |
| Cooling rate | RT + → -40 ℃ │ 60min (no-load nonlinear) |
| Humidity fluctuation | 3%R.H |
| Inner box material | SUS304 stainless steel |
| Enclosure Material | Stainless steel plate atomized (SUS #304) or cold plate paint (optional) |
| Thermal insulation material | Rigid Polyurethane Foam and Glass Cotton |
| Window size | 260X340x40mm 3-layer vacuum layer |
| Refrigeration system | Fully dense compressor imported from France |
| refrigerant | Environmentally friendly refrigerant R404A |
| Condenser | Fin type with cooling motor |
| Condenser | Fin type multi-stage automatic load Capacity adjustment |
| Display | Full Chinese LCD 7-inch 880 display LCD touch panel |
| Environment humidity | Not more than 85% |
| Humidity Control Accuracy | ±1%R.H |
| Controller Resolution | Temperature ± 0.1, Humidity 1% R.H. |
| Controller temperature slope | 0.1~ 9.9 can be set |
| Safety Devices | Upper and lower limit standby and alarm functions |
| Temperature and humidity input signal selection | PT 100Ω × 2 (dry and wet bulbs) |
| Temperature and humidity conversion output | 4～20MA |
| Controller | 6 groups of P.I.D control parameter setting, P.I.D automatic calculation, dry and wet bulb automatic correction |
| Display function | Screen direct display options, direct display of temperature and humidity settings (SV) and actual (PV) values (in English), current execution program number, segment number, remaining time and cycle number |
| Display function 2 | Running accumulated time function, temperature and humidity program settings are displayed in graphic Linear dispersion, with real-time display program Linear dispersion execution function |
| Available program groups | Up to 100 groups |
| Available memory Capacity | Total 5000SEGMENTS |
| Command, repeability | Each command can be up to 9999 times |
| SEGMENTS time setting | 0～530Hour59Min |
| Display when the program is executed | Real-time display of graphical Linear dispersion |
| Miscellaneous function | With date, time adjustment function, button and screen lock (LOCK) function |
| temperature control Accuracy | ±0.1℃ |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/34850/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
