Specifications
| Measurement principle | magnetic induction |
| Measuring range | 0.0 ~ 500µm |
| margin of error | ± (0.3 μm + 2%) five-point calibrated |
| resolution | 0.1mm | 1mm |
| Minimum measurement surface | F7mm |
| Minimum radius of curvature | Convex: 1.5mm; Concave: 10mm |
| thinnest matrix | 0.1mm |
| Probe size | F15 * 110mm |
| Probe Weight | 81g |
| Calibrated mode | Support zero point calibrate, 1 point to 5 point calibrate |
| Statistical function | MAX Maximum, MIN Minimum, Mean and Variance |
| Power | 4 1.5V AAA alkalinity batteries |
| Standards | GB/T 4956-2003、DIN EN ISO 2808、JJG-818-2005、 |
| Language | Chinese |
| Display screen | 240X160 dot matrix LCD |
| Operating Temperature | 0℃~50℃ |
| Total Weight | 194G (including battery) |
| Complete-built unit size | 148*76*26mm |
| matrix material | Ferromagnetic metal |
| Sexual repeability | ≤ ± (0.1μm + 0.8%) fixture test |
| Measurement interval | 1.5s |
| Storage temperature | -20℃~60℃ |
Packing list
Host x1, N1500 probe x1, zero adjustment board x1, standard sheet x7, manual x1, certificate/quality assurance card x1, 1.5V AAA alkalinity battery x4, plastic engineering box x1
After-sales instructions
Warranty days: 365 days
1. If the instrument and equipment are not artificially caused by product quality problems, the manufacturer provides 1 year free warranty service;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/34871/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
