Specifications
| Measurement principle | Magnetic Induction or eddy Current, determined by probe |
| Measurement range | Determined by the probe |
| margin of error | ±2~3.5％ |
| Minimum measurement surface | Φ25mm |
| Minimum radius of curvature | Convex: 5mm; Concave: 25mm |
| thinnest substrate | 0.2mm(F)；0.05mm(N) |
| statistical function | Average, MAX Maximum, MIN Minimum, Standard deviation (Storage only) |
| Interface | RS232 printing, computer (storage type only) |
| Data storage | 3900 Measured values, 999 datasets (storage only) |
| Power | 9V alkaline battery 1 |
| Display screen | LCD liquid crystal display |
| Operating temperature | －10~+60℃ |
| Machine Weight | 150g |
| Machine size | 110*60*24mm |
| Optional accessories | Standard film thickness sheet, probe lead, computer cable, software |
| Temperature compensation | 0~60℃ |
Packing list
whole machine X1, manual X1, certificate X1, warranty card X1, probe (purchased separately)
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/34876/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
