Specifications
| Grinding disc diameter | 240mm |
| load pressure | 43/64/100kg |
| Power | 220V 50Hz |
| Grinding disc speed | 75±5rpm |
| Counting range | 0~9999 |
| Counting range | 0~9999 |
| Overall Dimensions | 570*350*500mm |
| Weight | About 80kg |
| Motor power | 750W |
| Standards | GB/T 5211-16，GB/T 5211-19，GB/T 21867.1，GB/T 21868.5，ISO 787-16，ISO 787-17，ISO 8780-5，ISO 8781-1 |
| Load Weight | 1.75kg 、 1.75kg * 2 、 1.75kg * 2 + 2.92 |
Packing list
Plane grinding machine X1, plane grinding machine Glass X1, manual X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/34906/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
