Specifications
| basic structure | A. Turbine worm lift pot type; B. Double Stir shaft + scraping wall + dispersion |
| Stirring Barrel Specifications | Ø150mm×120mm |
| Stirring barrel design Volume | 1.95L |
| Stirring barrel working Volume | 1L |
| Stirring barrel liner material | SUS304 |
| Stirring Barrel Sheet Film thickness | 4mm |
| Stirring film thickness | 3mm |
| Stirring barrel Film thickness | 3mm |
| Stirring barrel liner | Mirror polishing after inner wall turning to ensure good roundness |
| Stirring barrel structure | Double jacketed type (with chill down layer), chill down inlet and outlet |
| Bucket cover structure | Observation port, lighting port, vacuum, vacuum, vacuum meter, spare port |
| Film thickness | 3mm |
| Bucket lid material | sus304 |
| Motor power | 0.37KW4P |
| Planet rotation speed | 0~51 rpm, adjustable |
| Wall scraper | Material: SUS304 and Teflon (with 2 Teflon scrapers) (optional) |
| Disperse motor power | 0.75KW |
| Disperse shaft and disc material | SUS304 stainless steel |
| Stirring shaft/Stirring speed | Rotation speed: 0~112rpm, adjustable; rotation speed: consistent with the planet's rotation speed |
| Impeller material | SUS304 |
| Number of Impellers | Two (groups) |
| Stirring pulp form selection | Twist |
| Lifting method | Mechanical turbo worm lift |
| Vacuumpump power | 0.25kw |
| Vacuum system | Oil Ring Vacuumpump with Vacuum Buffer Tank Design |
| Positioning system | With positioning adjustment and locking device to accurately position Stir barrels and prevent swirling/spinning |
| Total power | About 5kw |
| Machine Dimensions | 800 * 550 * 1000mm The specifics are subject to the actual product. |
| Weight | About 200KG |
| Equipment Appearance | Complete-built unit profile stainless steel housing |
Packing list
Complete-built unit x1, manual x1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/34991/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
