Specifications
| Cylinder | Specifications: inner diameter 250 * 150mm2, design Volume: 7.4L, effective Volume 5L3, material stainless steel, inner layer 316 Film thickness, 5mm; outer layer 304 stainless steel 4mm, thermal insulation layer 3mm4, liner wall after rounding, car processing, inner wall and outer wall mirror polishing, to ensure good roundness and smoothness 5, Stir barrel flange plane and upper barrel body through sealing ring 6, with water in and out DN25 water inlet and outlet, using fast-loading plug 7, quantity: 1 |
| kettle lid | A sight glass of φ 57 (with a small scraper of silicone sheet); a sight glass of φ 45 illumination spotlight; a feeding port DN57, a mechanical vacuum table; and Miscellaneous necessary pipe fittings (vacuum/venting/spare) |
| Circular/Stir motor and inverter, gear reducer | Motor power: 1.5Kw/4P 2, quantity: one 3, with 1.5KW variable frequency governor matched with the motor 4, matching gear reducer, reduction ratio I = 30, use factor fa = 1.55 |
| Planetary rotation speed | Speed: 0~48 rpm, adjustable |
| Gap reference value (optional) | Impeller and Impeller tolerances: 8 +/- 2.5 mm2, Impeller and bottom tolerances: 5 +/- 2.5 mm3, Impeller and barrel wall tolerances: 5 +/- 2.5 mm |
| Planetary rotation speed | Speed: 0~96rpm, adjustable |
| high speed dispersion | Motor power: 1.5kw/4p 2, quantity: 1 set 3, matching 1.5kw inverter, frequency conversion speed regulation 4, single dispersion shaft, install a layer of dispersion disc |
| dispersion speed | Speed: 0-2000rpm |
| Impeller | Material: 316 Material 2. Structure: Twist Impeller Leaf 3. Quantity: Two (Group) |
| Vacuum section | Vacuumpump 2, power: 0.75kw3, matching vacuum buffer tank 4, with automatic pressure relief |
| Screw lifting | Electric lift: φ 36 * s = 300; equipped with positioning device; positioning is safe and reliable. 2. Equipped with a geared motor and a 0.55Kw/4P motor; no oil leakage, low noise 3. Lifting height: ≤ 600. |
| Host electronic control | Operating Voltage/frequency: 380V/50Hz/3Phase 2, control Voltage: 220V.3, Total power of the host: about 6kw |
| Dimensions and Weight (reference) | Length, width and height: 1200 * 550 * 1500mm 2, Weight: about 600KG |
