Specifications
| Measurement range | 0.75~ 300mm (probe determined) |
| Probe style | Split probe |
| Probe Frequency | 5MHz probe |
| Speed of sound | 1000~9999m/s |
| Measurement error | ±(0.5%H+0.04)mm |
| Display resolution | 0.1/0.01mm |
| Lower limit of pipe measurement | Should be 20 * 3mm (5MHz probe); the error of indication should not exceed +/- 0.1 mm |
| Probe contact temperature | -10~60℃ |
| Data storage | 500 data read values stored, viewed, and deleted |
| Operating Time | 250H (no backlight) |
| Operating language | Chinese |
| Display | LCD screen |
| Host size | 150*74*32mm |
| Weight | 238g |
| Application | Metals (e.g. steel, cast iron, aluminium, copper, etc.), plastics, ceramics, Glass, fiberglass and Miscellaneous Thickness of any good conductor of ultrasonic waves |
| Power Supply | AA type alkaline battery 1.5V (2 *) |
| unit system | mm/inch |
| minimum thickness value capture capability | Capable of capturing minimum thickness values |
| Measurement speed | 4 times/sec for single point measurement, 20 times/sec for scanning mode |
| Calibrating block | 4.0 mm (steel) |
Packing list
Host X1, coupling agent X1, battery 2 (non-aviation) X2, 4.0 mm steel calibrated block X1, 5MHz probe X1, NDT310 host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
If the product quality is not artificially caused, the manufacturer provides 1 year warranty free of charge.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/3511/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
