Specifications
| Spreader thickness range | 0.01-10Mm drawdown blade can be lifted |
| Coating speed | 5~ 180Mm/s (< 5mm/s can be customized) |
| Coating size | 300*400mm |
| Spreader time | Digital display, different speed, time Accuracy control, |
| Coating rod specification | Standard 1 RDS9 stick + 1 China stick |
| Application width | 300mm |
| Drawdown blade length | 400MM material/stainless steel |
| Host Power | 220V 50Hz 1700W |
| Dimensions | 626*410*520mm |
| Weight | Net Weight 55KG |
| speed control | Infinitely variable speed |
| Bottom plate material | Glass plate |
| Customizable function | Jet system device, UV solid-containing device, automatic inking system |
Packing list
Film Applicator X1, Imported Wire Rod X1, China Wire Rod X1, doctor blade X1, product manual X1
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/35231/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
