Specifications
| Motor Power | 4KW |
| throughput | ≤ 6m ³/h (with water as the medium) Professional advice: for high viscosity material applications, an independent feed pump should be used; for low viscosity material applications with high shear emulsification pumps, this equipment has low lift and short distance transportation function. |
| input Voltage | 380V/50Hz |
| Motor type | Three-phase asynchronous motor |
| Rotation speed of motor | 3000rpm |
| Incoming and outgoing directions | Forward up and out, loop processing |
| Connectivity | flange connection |
| incoming and outgoing caliber | The inlet port DN40/outlet port DN32; the import and export Dimensions shall comply with the provisions of GB/T 9112. The diameter can also be designed according to the customer's existing kettle and tank. |
| rotating stator form | Level 3 |
| Emulsification form | Pipeline, continuous dispersion emulsification |
| Chill down system | Mechanical sealing adopts independent chill down form |
| Installation method | Fixed according to the site concrete base or expansion screw fixed |
| Homogeneous emulsification | Adopt online design, no dead ends, 100% of the material is homogenized through dispersion and shearing, low noise, smooth operation, suitable for |
| Operating Mode | Industrialized on-line continuous production, pipeline continuous dispersion shearing emulsification effect is good. |
| Sealing form | Double-end mechanical sealing) (water-cooled type); cemented carbide VS silicon carbide, mechanical sealing installation requirements; |
| other | Cavity and sealing chilled down water import and export 1/2 wire, the company provides water shortage protection switch, can linkage host Control system water shortage stop protection. |
