Specifications
| Power | 220V/50Hz |
| stirring amount | 300ml |
| Processing Capacity | 500ml |
| Processing Capacity | 1000mL |
| Operating temperature(MAX) | 120° |
| Heating mode | Water bath, oil bath circulation |
| reachable vacuum | -0.09Mpa (positive pressure optional) |
| Max. Processing Viscosity | 100000cp |
| Stirrer Power | 120W |
| Stirrer Rotation speed | 10~230rpm |
| Blade configuration | Anchor Scraper Impeller |
| Emulsification Homogenizer Power | 500W |
| Emulsification Homogenizer Rotation speed | 10000~28000rpm |
| Reaction Kettle Cover Opening | Homogenizer port + feeding port + temperature measurement port + vacuum port + 3 spare |
| Lifting method | Electric lift (manual optional) |
| Lifting stroke | 210mm |
| Contact material | SUS316L Stainless Steel + PTEF + Borosilicate Glass Sandwich Container |
| Outer diameter of vacuum port | 10mm |
| Glass container interlayer import and export | 12mm |
| Environmental temperature | 5~40℃ |
| Allowable Relative Humidity | 80% |
| Packing size | 400×390×780mm |
| Weight | 35Kg |
| Encasement mode | Encasement |
| Miscellaneous | Customizable |
