Specifications
| Capacity | 40L |
| Max Torque | 60N.cm |
| Motor input power | 120W |
| Motor output power | 100W |
| Weight | 2.8kg |
| Viscosity | 50000mPas |
| Speed range | 30~2200rpm |
| Speed display | LED |
| Speed display resolution | ±1rpm |
| Overload protection | Sound prompt, stop automatically |
| Motor protection | Sound prompt, stop automatically |
| Rotary collet clamping range | Ph0.5 ~ 10mm |
| Dimensions | 186*83*220mm |
| Protection class | IP42 |
| Allowable environment temperature | 5~40℃ |
| Allowable environment humidity | ≤80% |
| RS232 | without |
| Voltage | 100-240VAC |
| Rated frequency | 50/60HZ |
| Collet material | Stainless steel chuck |
| Time setting | without |
| Drive type | DC brushless motor |
Packing list
Host X1, power supply X1, instruction manual X1, universal flat bracket X1, stainless steel four-leaf Impeller, warranty card (including certificate of conformity) X1, instruction manual X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/35615/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
