Specifications
| Specifications | Multi-Manifold Gland Type |
| lyophilized area | 0.08㎡ |
| Number of vials | Φ12mm 560、Φ16mm 285、Φ22mm 165 |
| Cold trap size | Φ220*220mm |
| cold trap temperature | -60℃ |
| Replenishment Capacity (kg/batch) | 4 |
| standard vacuum | ≤ 5Pa (no load) |
| Ultimate Vacuum | 2PA |
| Material tray size | 180Mm 3 layers in total |
| Rated Power | 1050W |
| Host Weight | 100kg |
| Dimensions | 600*558*760mm |
| Power supply Voltage | AC220V25A50HZ |
| Applicable environment | Environmental temperature ≤ 30 ℃ |
| Whole machine running noise | ≦55dB |
