LEBO EZ8-S Spin Coater

The LEBO EZ8-S homogenizer has a safety interlock function with vacuum switch and lid switch. The maximum recommended spinning coating substrate size of the EZ8-S homogenizer is 8 inches round substrate, Speed range 100-12000rpm, Acceleration range 100-30000rpm/s.
Model：
Certificate
Contact
Details SPEC

lebo EZ8-S Glue levelerSPEC

lebo EZ8-S Glue levelerDetails

lebo EZ8-S Glue levelerPacking list

SKU
NB035698
Maximum processing size
8 inch
Speed range
100~12000rpm
Acceleration range
100~30000rpm/s
Speed Accuracy
±2rpm
maximum single step size
3000s
Time resolution
0.1s
Program settings
100 steps 100 groups
Automatic dispensing port
4 pieces
Swirl/spinning motor
BLDC
Vacuum and open lid interlock
Yes.
Human Machine Interface
7 inch touch screen
lumen material
HDPE
Shell material
PP
Waste outlet
Yes.
Draw trends
Yes.
Disk form
sheet tray
Embedded Design
none
Dimensions
315*358*370mm
EZ8-S
Glue leveler
LEBO EZ8-S Spin Coater Picture

Features

  • Industrial-grade BLDC motor and PLC control

  • 7-inch full-color touch screen, graphical interface

  • Glue bottles are placed on the side to facilitate the recycling of waste glue

  • Simple and reliable vacuum tray sleeve ring design

  • It can be upgraded with four-channel precisIon Metering and automatic dispensing function

  • With vacuum switch and lid switch safety interlock function

  • Ultra-polymer material inner cavity with lower exhaust, PP shell

  • Maximum recommended spin-coated substrate size: 8 inch round substrate

Product parameters

  • Speed range: 100-12000rpm; RPM resolution: ±1rpm

  • Acceleration adjustable range: 100-30000rpm/s

  • SINGLE-STEP DURATION: 3000S; Temporal resolution: 0.1S

  • Single-step and multi-step operation are optional, and 100 groups of 100-step programs can be programmed

  • Wide Voltage application: AC100-230V input, Chinese and English interface optional

  • It is equipped with 100mm master disk, 10mm, 25mm and 55mm sub-disks as standard

  • Dimension:315mm(W)*358mm(D)*370mm(H)


FAQ
QIs the price listed on the website the final cost for overseas purchases?
ANo, it isn't. This is the ex-factory price of the product in the Chinese Mainland. In addition to this price, buyers from different countries need to account for additional costs such as shipping fees, tariffs, and others. For specific regional quotes, please consult our customer service or fill out a quotation form.
QWhat is the specific process for purchasing the product?
AFirst, please click on the quotation form on the website and fill in detailed information. Our customer service personnel will then send you a quotation based on your specific country and region, confirming payment and delivery methods. Following this, we proceed with contract signing, payment, and shipment. You can then await delivery.
QWhat should I do if the instrument I purchase needs repair?
AAfter-sales repair for overseas instruments is an unavoidable issue. Our repair terms stipulate that the sender is responsible for the shipping and insurance costs incurred for the repair. Repairs within the warranty period are free, while repair costs beyond the warranty period are determined based on the actual situation.
