Specifications
| Measurement principle | Magnetic Induction |
| Measured object | Iron based coatings |
| Measurement range | 0~1500μm |
| margin of error | ±0.75% |
| Minimum measurement surface | 5mm |
| Data storage | 10,000 readings |
| system language | 20 kinds |
| Interface | Bluetooth |
| statistical function | Number of readings, MIN Minimum, MAX Maximum, mean, standard deviation, coefficient of variation, single-valued statistics, chunk statistics (conforming to specifications/free configuration) |
| Calibrated mode | Factory calibrated, zero calibrated, 2 point calibrated, 3 point calibrated, rough Calibration method "rough" |
| Calibrate to international standards and norms | ISO international standards organization, SSPC American protective coatings association, "Swedish" Sweden, "Australian" Australia |
| limit monitoring | Output visual and auditory signals |
| Unit display | μm/mm/cm/mils/inch/thou |
| Measurement speed | 70 readings per minute in single-value mode; 20 readings per second in continuous mode |
| continuous mode | For quickly identifying thickness changes |
| operating temperature | -10℃~60℃ |
| Storage temperature | -20~70℃ |
| Interface | USB、Bluetooth |
| Power Supply | 2 AA (AA) batteries; optional rechargeable nickel-metal hydride battery, AA/HR6 type. Battery or rechargeable battery settings are optional to match Rated Voltage. |
| Standards | DIN EN ISO1461、2064、2178、2360、2808、3882、19840、ASTM B244、B499、D7091、E 376、AS 3894.3、SS 1841 60、SSPC-PA 2 |
| Display screen | LCD screen |
| Dimensions | 157*75.5*49mm |
| Weight | 210g |
Packing list
After-sales instructions
Warranty days: 365 days
