Specifications
| Power | AC110～220V |
| Power | 50/60Hz |
| Equipment applicable Voltage | DC 24V |
| Input power | 368W |
| Input power | 250W |
| Impeller fixing method | Quick turn chuck |
| Rotary collet clamping range | 1~10mm |
| Impeller type | Four-blade propeller |
| Maximum Max. Viscosity | 100000mPa.s |
| Running status display | TFT color screen |
| Operation control method | Digital knob |
| Speed range | 0~2000rpm |
| Speed dynamic detection function | Yes |
| Speed trend Linear dispersion | Yes |
| Speed memory function | Yes |
| Overload protection | Yes |
| Allowable environment temperature | 5～40℃ |
| Allowable environment humidity | 80％ |
| Protection class | IP40 |
| Complete-built unit form factor | 215*310*700mm |
| Total Weight | About 8kg |
Packing list
Stir host * 1, base * 1, column * 1, pillar * 1, support fixing frame * 1, column prototype * 1, stirringrod * 1, power box * 1, certificate of conformity * 1, manual * 1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/35732/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
