Specifications
| matrix material | Fe |
| Probe position | Integrated type |
| Resolution | 0.1μm|1μm |
| Measurement range | 0~1250μm |
| margin of error | Zero correction : +/- ( 3% H + 1) μm; two-point correction : +/- ( 1~ 3% H + 1.5) μm; |
| Small measurement size | 10×10mm |
| Minimum substrate thickness | Magnetic: 0.2mm |
| Minimum radius of curvature | Convex radius 5mm; Concave radius 10mm |
| Unit display | μm |
| Power Supply | 2 AA alkaline batteries or NiMH rechargeable batteries; |
| Dimensions | 102*66*24mm |
| Weight | 99G (including battery) |
| Operating temperature | 0~40 ℃ (10~90% RH without condensation) |
| Storage temperature | -10~50℃ |
| Standard Accessories | 1 piece base (iron base), wrist strap, calibrated test piece |
| Optional accessories | Calibrated specimens (12 μm, 25 μm) |
