Specifications
| Lighting method | Transmission: 0/D (parallel light illumination, diffuse reflection reception) |
| Standards | ASTM D1003/1044,ISO 13468,ISO 14782,GB/T 2410,JJF 1303-2011,CIE 15.2,GB/T 3978,ASTM E308,JIS K7105,JIS K7361,JIS K 7136 |
| Integrating sphere size | F154mm |
| lighting source | 400~700Nm combined LED light source |
| sensor | PD Array Detector with CIE V (λ) 2 Degree Visual Response |
| Transmittance range | 0~100% |
| Measurement aperture | F4mm |
| Sample size | Film thickness less than 105mm |
| Other chromaticity indicators | Haze (ASTM D1003/1044, ISO 13468), light transmitance T (ISO), light transmitance T (ASTM) |
| Observer angle | 2° |
| Observation light source | D65,A,C |
| show | Pass/Fail Results |
| Measurement time | About 1.5s |
| haze resolution | 0.01 unit |
| Haze, sexual repeability | Φ20mm diameter, less than 0.05 (after the instrument is preheated and corrected, the standard haze sheet with a haze of about 40 is tested 30 times at an interval of 5s) |
| Inter-station difference | Φ20mm diameter, less than 0.4 (after the instrument is preheated and corrected, the standard deviation between the standard haze sheet and the reference value is tested at intervals of 5s) |
| size | Length X width X height = 487X260X298mm |
| Weight | Approx. 8.0kg |
| Power Supply | DC 24V, 3A power adapter Power |
| Lighting source life | 5 years more than 3 million measurements |
| Display | TFT true color 7inch, capacitive touch screen |
| interface | USB, print serial port |
| Store data | 1000 master standards, 20,000 samples |
| language | Simplified Chinese, Traditional Chinese, English |
| Operating temperature range | 0~40℃（32~104°F） |
| Storage temperature range | -20~50℃（-4~122°F） |
Packing list
Host X1, power adapter X1, quality management software (official website download) X1, data cable X1, calibration box X1, measurement diameter X1, manual X1, certificate X1, warranty card X1
