Specifications
| Lighting method | Transmission: 0/D (parallel light illumination, diffuse reflection reception) |
| Integrating sphere size | F154mm |
| lighting source | 400~700Nm combined LED light source (wavelength can be expanded and customized) |
| Spectroscopic method | Concave grating |
| sensor | 256-Pixel dual array CMOS image sensor |
| Measurement Wavelength range | 400~700Nm (wavelength can be expanded and customized) |
| wavelength spacing | 10nm |
| Half Bandwidth | 10nm |
| Transmittance range | 0~100% |
| Measurement aperture | F15mm |
| Sample size | Film thickness less than 170mm |
| Color space | CIE LAB,XYZ,Yxy,LCh,s-RGB,βxy |
| Color difference formula | ΔE*ab,ΔE*94,ΔE*cmc(2:1),ΔE*cmc(1:1),ΔE*00 |
| Other chromaticity indicators | Haze (ASTM D1003/1044, ISO 13468), light transmitance T (ISO), light transmitance T (ASTM) WI (ASTM E313, CIE/ISO, AATCC, Hunter), YI (ASTM D1925, ASTM 313), Absorbance, Cobalt Platinum Index, Gardner Index |
| Observer angle | 2°/10° |
| Observation light source | D65,A,C,D50,D55,D75,F1,F2,F3,F4，F5，F6,F7,F8,F9，F10,F11,F12 |
| show | Light spectrum diagram, sample chromatic value, color difference value/diagram, chromaticity diagram, Color simulation, pass/fail results |
| Measurement time | About 1.5s |
| haze resolution | 0.01 unit |
| Haze, sexual repeability | Φ20mm diameter, less than 0.05 (after the instrument is preheated and corrected, the standard haze sheet with a haze of about 40 is tested 30 times at an interval of 5s) |
| Inter-station difference | Φ20mm diameter, less than 0.4 (after the instrument is preheated and corrected, the standard deviation between the standard haze sheet and the reference value is tested at intervals of 5s) |
| size | Length X width X height = 290X211X511mm |
| Weight | About 7.6kg |
| Power Supply | DC 24V, 3A power adapter Power |
| Lighting source life | 5 years more than 3 million measurements |
| Display | TFT true color 7inch, capacitive touch screen |
| interface | USB, print serial port, Bluetooth |
| Store data | 5000 master standards and 20,000 samples |
| language | Simplified Chinese, Traditional Chinese, English |
| Operating temperature range | 0~40℃（32~104°F） |
| Storage temperature range | -20~50℃（-4~122°F） |
| Standards | ASTM D1003/1044,ISO 13468,ISO 14782,GB/T 2410,JJF 1303-2011,CIE 15.2,GB/T 3978,ASTM E308,JIS K7105,JIS K7361,JIS K 7136 |
Packing list
Host X1, power adapter X1, quality management software (official website download) X1, data cable X1, calibration box X1, measurement diameter X1, manual X1, certificate X1, warranty card X1
