Specifications
| Lighting method | Transmission: 0/D (parallel light illumination, diffuse reflection reception); Compliant with standards: ASTM D1003/1044, ISO 13468, ISO 14782, GB/T 2410, JJF 1303-2011, CIE 15.2, GB/T 3978, ASTM E308, JIS K7105, JIS K7361, JIS K 7136 |
| Integrating sphere size | F154mm |
| lighting source | 400~700Nm combined LED light source (wavelength expandable needs to be customized) |
| Spectroscopic method | Concave grating |
| sensor | 256-Pixel dual array CMOS image sensor |
| Measurement Wavelength range | 400~700Nm (wavelength expandable needs to be customized) |
| wavelength spacing | 10nm |
| Half Bandwidth | 10nm |
| Transmittance range | 0~100% |
| Measurement caliber | F15mm |
| Sample size | Film thickness less than 105mm |
| Color space | CIE LAB,XYZ,Yxy,LCh,s-RGB,βxy |
| Color difference formula | ΔE*ab,ΔE*94,ΔE*cmc(2:1),ΔE*cmc(1:1),ΔE*00 |
| Other chromaticity indicators | Haze (ASTM D1003/1044, ISO 13468), Transmittance T (ISO), Transmittance T (ASTM), Clarity WI (ASTM E313, CIE/ISO, AATCC, Hunter), YI (ASTM D1925, ASTM 313), Absorbance, Cobalt Platinum Index, Gardner Index |
| Observer angle | 2°/10° |
| Observation light source | D65,A,C,D50,D55,D75,F1,F2,F3,F4，F5，F6,F7,F8,F9，F10,F11,F12,CWF,DLF,TL83,TL84,TPL5,U30 |
| show | Light spectrum diagram, sample chromatic value, color difference value/diagram, chromaticity diagram, Color simulation, pass/fail results |
| Measurement time | About 1.5s |
| haze resolution | 0.01 unit |
| Haze, sexual repeability | Φ20mm diameter, less than 0.05 (after the instrument is preheated and corrected, the standard haze sheet with a haze of about 30 is tested 30 times at an interval of 5s) |
| Inter-station difference | Φ20mm diameter, less than 0.4 (after the instrument is preheated and corrected, the standard deviation between the standard haze sheet and the reference value is tested at intervals of 5s) |
| size | Length X width X height = 487X260X298mm |
| Weight | Approx. 8.0kg |
| Power Supply | DC 24V, 3A power adapter Power |
| Lighting source life | 5 years more than 3 million measurements |
| Display | TFT true color 7inch, capacitive touch screen |
| interface | USB, print serial port, Bluetooth |
| Store data | 5000 master standards and 30,000 samples |
| language | Simplified Chinese, Traditional Chinese, English |
| Operating temperature range | 0~40℃（32~104°F） |
| Storage temperature range | -20~50℃（-4~122°F） |
Packing list
Host X1, power adapter X1, quality management software (official website download) X1, data cable X1, calibration box X1, measurement diameter X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 1095 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/35832/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
