Specifications
| Optical inspection system | Optical inspection system for color difference correction |
| observation tube | 30 ° tilt, hinged trinocular observation cylinder, 360 ° swirl/spin, pupil distance adjustment range: 50-75mm, bilateral vision adjustment: +/- 5 diopters, fixed spectral ratio, binocular: trinocular = 80:20. |
| eyepiece | High eye point and large field of view flat field eyepiece PL10X/18mm |
| Long distance flat field color difference objective | LMPL5X /0.13 WD15.5mm，LMPL10X/0.25 WD8.7mm，LMPL20X/0.40 WD8.8mm，LMPL50X/0.60 WD5.10mm |
| converter | Internal positioning four-hole converter |
| Focusing mechanism | Low hand position coarse micro coaxial focusing mechanism, fine-tuning Accuracy of 0.002mm, with anti-sliding adjustment elastic device and mechanical upper limit device. |
| stage | Compound double-decked mechanical moving platform, table size 140 * 132mm, moving range: 76mmX50mm, Accuracy 0.1mm. |
| Reflection lighting system | Reflection Cora lighting, adaptive wide Voltage 100V-240V, 5W LED warm color, Light intensity continuously adjustable, with variable aperture diaphragm and field diaphragm, field diaphragm center adjustable |
| Metallographic analysis system | FMIA2024 genuine metallographic analysis software, 5 million Sony chip camera device, 0.5X adapter mirror interface, micrometer. |
| eyepiece | High eye point large field of view flat field eyepiece PL10X/18mm, with micrometer, high eye point large field of view eyepiece WF15X/13mm, high eye point large field of view eyepiece WF20X/10mm |
| objective lens | Long distance flat field color difference elimination objective LMPL100X/0.80 WD2.0mm |
| converter | Internal positioning five-hole converter |
| Transmission lighting system | Adaptive 100V-240V wide Voltage, single high-power 5W LED, warm color |
| condenser | Abbe condenser, numerical aperture N.A.1.25. |
| Polarized Accessories | Polarizer insert, polarizer insert |
| Color filter | Yellow, green, blue, neutral color filters |
| computer | HP Business Jet (computer optional) |
Packing list
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/35848/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
