Specifications
| Coating method | Wire Rod Coating |
| Coating size | 300*400mm |
| Application width | 300mm |
| Coating speed | 5~ 180Mm/s (< 5mm/s can be customized) |
| Spreader thickness range | With 1 China wire rod and 1 imported wire rod with 11 μm film |
| Temperature display Accuracy | ±2℃ |
| Vacuum pump configuration | external |
| Vacuum Area | 300 * 400Mm (can be customized) |
| Vacuum aperture | Φ1.2mm |
| Key control mode | Touch screen control |
| Regulator display Accuracy | ±0.001mm |
| Display | digital |
| Total power consumption | 2060W |
| Host Power | 220V 50Hz |
| Dimensions | 690*410*520mm |
| Machine Weight | 65Kg |
| Bottom plate material | aluminum alloy |
| Vacuum pump size | 380*180*280mm |
| Optional | Substrate fixture, trimming horizontal height support foot device, Glass plate, Silicone pad and Weight (for applications with uneven substrate thickness of Spreader) |
| Customizable function | Jet system device, UV solid-containing device, automatic inking system |
| speed control | Infinitely variable speed |
Packing list
Film Applicator X1, Imported Wire Bar X1, China Wire Bar X1, External Vacuum Pump X1, Product Manual X1
