Specifications
| Coating speed | 5~ 180Mm/s (< 5mm/s can be customized) |
| Coating size | 300*400mm |
| Coating rod specification | Standard 1 1μm Accuracy China wire rod and 1 0.1μm Accuracy imported wire rod + ZUA2000.150 adjustable preparer |
| Spreader displacement | Digital display, different speeds, displacement Accuracy control |
| Host Power | 220V 50Hz |
| Dimensions | 650*410*520mm |
| Weight | Net Weight 45KG |
| speed control | Infinitely variable speed |
| Bottom plate material | aluminum alloy |
| Optional | Substrate fixture, trimming horizontal height support foot device, Glass plate, Silicone pad and Weight (for applications with uneven substrate thickness of Spreader) |
| Customizable function | Jet system device, UV solid-containing device, automatic inking system |
Packing list
Film Applicator X1, Imported Wire Rod X1, China Wire Rod X1, Product Manual X1
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/35867/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
