Specifications
| Coating speed | 5~ 180Mm/s (< 5mm/s can be customized) |
| Coating size | 300*400mm |
| Spreader speed | Digital display, different speeds |
| Vacuum Area | 300 * 400Mm (can be customized) |
| Vacuum aperture | Φ1.2mm |
| Vacuum hole spacing | 20*20mm |
| Coating rod specification | 1 Accuracy 1μm China wire rod + 1 Accuracy 0.1μm imported wire rod, effective application width 300mm (Spreader thickness is determined according to the wire rod model) |
| Host Power | 220V 50Hz |
| Dimensions | 630*410*520mm |
| Weight | 65kg |
| speed control | Infinitely variable speed |
| Bottom plate material | aluminum alloy |
| Heating temperature range | RT+~200℃ |
| Temperature Uniformity | ±3℃ |
| Power | 1500W |
| Vacuum pump size | 380*180*280mm |
| Optional | Substrate fixture, trimming horizontal height support foot device, Glass plate, Silicone pad and Weight (for applications with uneven substrate thickness of Spreader) |
| Customizable function | Jet system device, UV solid-containing device, automatic inking system |
Packing list
Film Applicator X1, External vacuum pump X1, doctor blade X1, imported wire rod X1, China wire rod X1, product manual X1
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/35868/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
