Specifications
| range of travel | 10-200mm |
| Speed range | 10-200mm/s |
| speed buffering | 10±1mm |
| Diameter of metal scraper head | 0.5mm、0.75mm、1mm（Erichsen318）、3mm、5mm、7mm,1.4mm |
| Metal scraper head material | Tungsten Carbide uses tungsten carbide as a scraping finger to accurately detect surface wear that is damaged by unconventionally defined physical forms such as scraping, scratching, planing, etc. |
| Pressurized Weight and total Weight of scraping components | 2N, 3N, 5N, 7N, 8N, 10N, 12N, 15N, 20N (optional) The Mass error does not exceed 1%, and the customized Weight is optional |
| Plastic scraping finger | Polymethyl methacrylate (PMMA) |
| diameter | 16mm |
| Film thickness | 1mm |
| Scrape the radius of the edge | 0.5mm |
| Hardness | shore D8528 |
| Dimensions | 770×550×500mm |
| Weight | 50Kg |
| Power | AC220V±10% 50Hz |
Packing list
Host, weight, China tungsten carbide scraper head, manual, certificate of conformity, warranty card
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/35896/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
