HUITAO CSI-456 Pencil Hardness Tester film Hardness evaluator 45 ° angle test

CSI-456

Pencil Hardness Tester

Adopt 45 ° angle test design, support 0.5~ 1mm/s scratch speed, maximum load 1kgf, equipped with automatic sample base and pencil swirl/spin device, easy to operate and accurate test.

Application

This Tester is used to evaluate the hardness of the coating film. Scratch the surface of the film with a pencil at a 45° angle. The operator should be sure that the hardest pencil will not tear or damage the film. The Tester can also be used to evaluate the hardness of decorative panels and the resistance of solvents on enamelled wire.

Standards

JIS-C3003, D0202, (K5400), K5600-5-4, K5651, K6894, K6902, ASTM-D2197, D3363, ISO-15184, GB/T6739

Instructions

Scratch the surface of the coating film with a hardness pencil to test the surface hardness of the coating film layer. The hardness pencil is fixed at an angle of 45°, so that the tip of the tip is in contact with the surface of the coating film layer, and an appropriate load is applied at a certain speed (jis specification 0.5mm/second) The mobile test platform makes the surface of the coating layer move past the core, and the softest pencil grade that will not cause damage (scratches) to the coating layer can be regarded as the hardness of the coating layer.

Packing list：host X1, manual X1, certificate X1, warranty card X1

[Note]Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
