TENLIN DC-0520 Vertical Low Temperature Circulating Bath - 5 ℃/ +/- 0.05 ℃ 20L

DC-0520

Vertical Low Temperature Circulating Bath

-5~ 100 ℃, Temperature resolution 0.01 ℃, Temperature Fluctuation +/- 0.05 ℃, Power 2.3kw, Tank volume 20L, Tank opening dimensions 250 * 160mm, Tank depth 300mm, Pump Flow rate 6L/min.

Features

● New self-developed temperature control technology, equipped with high-standard PT100 and fully imported electronic components.

● The software system can correct the error between the displayed temperature and the actual temperature, so that the displayed temperature value is accurate.

● Standard large-screen LCD display, a number of data at a glance, temperature display resolution up to 0.01°C.

● With over-temperature protection, over-temperature alarm alarm, over-temperature alarm temperature can be set, and the load can be automatically cut off when over-temperature.

● With timing function, the total working time of the equipment can be set, and the load will be automatically cut off at that time.

● Concealed cooling coil design ensures a larger space in the tank.

● Intelligent software has strong temperature stability, PID can automatically set appropriate parameters according to different media, and special users can also manually readjust the parameters.

● Use software to digitally lock the setting values of the control system to avoid misoperation by irrelevant personnel and ensure the correctness of the experimental process data.

● Effective fully enclosed compressor refrigeration, fast cooling speed, with multiple protections such as overheating and overcurrent.

● Standard internal and external circulation function, external circulation inlet and outlet outer diameter of 10mm round pipe, to meet the different needs of users in multiple scenarios.

● Support non-standard customization.

Optional

Liquid level protection system 1 - exceeds the limit liquid level, forcibly stops the load, and escorts the user's experiment.

RS485 communication interface - connect to the computer and other host computers, and control the equipment and view data by the host computer software.

Multi-point correction function - multiple temperature points can be corrected at the same time to avoid temperature differences caused by linearity errors of the sensor.

External PT100 - can realize precise temperature control of external circulation.

Bracket - to meet the needs of different containers placed in the tank, to avoid submerging the constant temperature liquid.

Exterior structure

Figure 1: DC thermostat outline

Figure 2: DC bath control panel

Model parameters

Packing list：host X1, cover X1, manual X1, certificate X1, warranty card X1

[Note]Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
