TENLIN BD-3030 High Accuracy Low Temperature Circulating Bath - 30 ℃/ +/- 0.01 ℃ 30L

SE
-30~ 100 ℃, Temperature resolution 0.001 ℃, Power 2.7kw, Tank volume 30L, Tank opening dimensions 330 * 280mm, groove depth 230mm, circulation mode domestic circulation.
Model：
Certificate
Contact
Details SPEC CAT OI
Similar products

TenLin BD-3030 High Accuracy Low Temperature Circulating BathSPEC

TenLin BD-3030 High Accuracy Low Temperature Circulating BathDetails

TenLin BD-3030 High Accuracy Low Temperature Circulating BathPacking list

SKU
NB035994
Temperature range
-30~100℃
temperature resolution
0.001℃
Temperature fluctuation
±0.005~0.01℃
Dimensions
450*540*990mm
power
2.7kw
Tank Volume
30L
Tank opening Dimensions
330*280mm
groove depth
230mm
Circular mode
Domestic circulation
BD-3030
High Accuracy Low Temperature Circulating Bath
-30~ 100 ℃, Temperature resolution 0.001 ℃, Power 2.7kw, Tank volume 30L, Tank opening dimensions 330 * 280mm, groove depth 230mm, circulation mode domestic circulation.
TENLIN BD-3030 High Accuracy Low Temperature Circulating Bath - 30 ℃/ +/- 0.01 ℃ 30L Picture

Features

1. Refrigeration system: It adopts low-noise air-cooled hermetic compressor unit, which has the advantages of fast refrigeration speed and strong temperature stability.

2. Control system: new special software research and development of self-made temperature control technology, equipped with high-standard Pt100 and all imported electronic components.

3. Circulation system: It is composed of internal and external circulation. During the external circulation, the constant temperature liquid in the tank can be introduced outside, and a second constant temperature field can be established. It can also be used as a cold source to guide the refrigerated liquid in the tank to the external experimental container to cool down. When circulating, the temperature of the liquid in the tank can be very uniform and stable.

4. Protection system: Refrigeration has overheating and overcurrent protection. The control system has functions such as over-temperature chirp alarm, upper and lower limits of temperature can be set for over-temperature alarm temperature, and the load can be automatically cut off when over-temperature.

5. High-end large LCD control instrument, easy to operate, strong temperature stability, PID can be automatically searched or manually adjusted.

6. The accurate temperature correction function can reach 0.01°C, and the temperature fluctuation can reach up to ±0.005-0.01°C (depending on the model).

external structure

TENLIN BD-3030 High Precision Low Temperature Constant Temperature Bath Details Figure 1

Figure 1: Outline structure of constant temperature bath

TENLIN BD-3030 high-precision low-temperature constant temperature bath details Figure 2

Figure 2: Bath control panel

Model parameters

modeltemperature rangeresolutionVolatilityDimensionspowervolumeslot openinggroove depthcycle mode
BD-0506-5~100℃0.001°C±0.005-0.01℃320*370*675mm0.8kw6L180*150mm150mmInner loop
BD-1006-10~100℃0.001°C±0.005-0.01℃320*370*675mm0.9kw6L180*150mm150mmInner loop
BD-2006-20~100℃0.001°C±0.005-0.01℃320*370*675mm1kw6L180*150mm150mmInner loop
BD-3006-30~100℃0.001°C±0.005-0.01℃320*370*765mm1.5kw6L180*150mm150mmInner loop
BD-4006-40~100℃0.001°C±0.005-0.01℃400*450*940mm2.1kw6L180*150mm150mmInner loop
BD-0510-5~100℃0.001°C±0.005-0.01℃320*370*765mm1.3kw10L180*150mm200mmInner loop
BD-1010-10~100℃0.001°C±0.005-0.01℃320*370*765mm1.5kw10L180*150mm200mmInner loop
BD-2010-20~100℃0.001°C±0.005-0.01℃320*370*765mm1.8kw10L180*150mm200mmInner loop
BD-3010-30~100℃0.001°C±0.005-0.01℃320*370*765mm2kw10L180*150mm200mmInner loop
BD-4010-40~100℃0.001°C±0.005-0.01℃400*450*940mm2.1kw10L180*150mm200mmInner loop
BD-0515-5~100℃0.001°C±0.005-0.01℃320*370*765mm2.1kw15L250*160mm200mmInner loop
BD-1015-10~100℃0.001°C±0.005-0.01℃320*370*765mm2.2kw15L250*160mm200mmInner loop
BD-2015-20~100℃0.001°C±0.005-0.01℃320*370*765mm2.3kw15L250*160mm200mmInner loop
BD-3015-30~100℃0.001°C±0.005-0.01℃320*370*765mm2.4kw15L250*160mm200mmInner loop
BD-4015-40~100℃0.001°C±0.005-0.01℃400*450*940mm2.5kw15L250*160mm200mmInner loop
BD-0520-5~100℃0.001°C±0.005-0.01℃400*450*1040mm2.3kw20L250*160mm300mmInner loop
BD-1020-10~100℃0.001°C±0.005-0.01℃400*450*1040mm2.4kw20L250*160mm300mmInner loop
BD-2020-20~100℃0.001°C±0.005-0.01℃400*450*1040mm2.5kw20L250*160mm300mmInner loop
BD-3020-30~100℃0.001°C±0.005-0.01℃400*450*1040mm2.6kw20L250*160mm300mmInner loop
BD-4020-40~100℃0.001°C±0.005-0.01℃450*540*1090mm2.7kw20L250*160mm300mmInner loop
BD-0530-5~100℃0.001°C±0.005-0.01℃450*540*990mm2.5kw30L330*280mm230mmInner loop
BD-1030-10~100℃0.001°C±0.005-0.01℃450*540*990mm2.6kw30L330*280mm230mmInner loop
BD-2030-20~100℃0.001°C±0.005-0.01℃450*540*990mm2.7kw30L330*280mm230mmInner loop
BD-3030-30~100℃0.001°C±0.005-0.01℃450*540*990mm2.7kw30L330*280mm230mmInner loop
BD-4030-40~100℃0.001°C±0.005-0.01℃450*540*1090mm3kw30L330*280mm230mmInner loop



FAQ
QThermostatic bath can be applied to GB/T26808?
A OK
QWhat is the minimum temperature of BD-3030 Thermostatic bath?
A TENLIN BD-3030 meets the Temperature range of -30 to 100 ° C, with a minimum temperature of -30 ° C.
QCan I set an alarm if the temperature is too high or too low?
A Refrigeration with overheating, overcurrent protection, control system with over-temperature alarm, can set the upper and lower limits of temperature over-temperature alarm temperature, over-temperature can automatically cut off the load and other functions.
QWhat is the Thermostat cycle for this series?
A There are internal and external circulation components, the external circulation can lead the thermostatic liquid in the tank, the second thermostatic field can be established, and the cooled liquid in the tank can also be used as a cold source to cool the experimental container outside the machine. The temperature of the liquid in the tank can be uniform and stable during domestic circulation.
