Specifications
| Coating method | Rod |
| Mayer Rod Thickness Range | 1-571.5 μm (Spreader thickness according to bar model) |
| Mayer Rod Accuracy | ±0.001mm |
| application width | 480mm |
| Coating speed | 5-200Mm/s (< 5mm/s can be customized) |
| Vacuum pump configuration | external |
| vacuum aperture | Φ1.2mm |
| Control mode | Touch screen control |
| Substrate clamping method | Vacuum adsorption |
| Total power consumption | 2060W |
| Host Power Supply | 220V 50Hz |
| Dimension | 852*645*500mm |
| Machine Weight | 65Kg |
| Bottom plate material | aluminum alloy |
| Vacuum pump size | 380*180*280mm |
| Optional Accessories | Leakage tank, substrate fixture, trimming horizontal height support foot device, Glass plate, silicone pad and Weight (for applications with uneven thickness of Spreader substrate), application width control baffle |
| customizable function | Automatic lame plating device, UV curing device, automatic inking system, air knife drying, remote control, upper infrared heating, double extrusion Spreader |
Packing list
Film Applicator x1, External vacuum pump x1, Operation manual x1 (imported bar optional)
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/36189/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
