Specifications
| Resolution | Readings of 0.1 pm or < 0.2% (detection range up to 1.5 mm) 1 pm or < 0.2% (detection range greater than 1.5 mm) |
| Display screen | High resolution color graphics display, backlit |
| system language | Menu-driven, available in English, German, French, Chinese |
| memory | Direct mode: F mode and N mode MAX Maximum each: 1000 readings Data file mode: MAX Maximum: 1000 readings |
| Calibrated mode | Engineering calibrated zero position adjustment (single point calibrated) foil calibrated (double point calibrated) double foil calibrated by Cal coating calibrated Cal-Through-Coat calibration |
| zero offset | Add a constant scale to the reading |
| statistical function | N, x^, a, Max, Min, Cp, Cpk, Kvar |
| Online statistics | N, x^, a, Max, Min |
| finite value | Debuggable audio signals and indicators on the monitor |
| interface | USB 2.0, Bluetooth 4.0 |
| room temperature | 0 ... 50 ℃ |
| Power Supply | 3 x batteries AAA 1.5 V |
| Dimensions | 163*82*40mm |
| Weight | Approx. 290 g (including battery) |
| Protection level | IP52 |
Packing list
Host X1, Probe X1, Standard Sheet X5, Iron Substrate (or Aluminum Substrate) X1, Product Encasement Box X1, Instruction Manual X1, Communication Cable X1, Communication Software X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/36257/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
