Specifications
| Measurement range | 170~960HLD |
| Measurement direction | 360° |
| Impact device | D type |
| Hardness system | HL，HB，HRB，HRC，HRA，HV，HS |
| optional materials | 10 kinds |
| Calibrate | standard test block |
| Display | OLED display |
| Measured value storage | 350 data sets |
| Alarm function | MAX Maximum or MIN Minimum |
| Automatic shutdown function | Yes |
| Power Supply | 2 CR2016 button batteries |
| Interface | USB |
| Operating temperature | 0~50℃ |
| size | 145.5x32x26mm |
| Weight | 160g |
Packing list
Host X1, USB cable X1, hardness testing block X1, cleaning brush X1, support ring X1, transport box X1, user manual X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/36262/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
